12. DISPLAY/SET/EDIT
B–64113EN–1/01
870
NOTE
1 The machine condition select function requires any of the
APC, AI–APC, and AI contour control functions.
2 Using the bell–shaped acceleration change time for AI
contour control requires the ”pre–read pre–interpolation
bell–shaped acceleration/deceleration” option.
3 The effective value of items is rewritten when:
– The precision level is changed, or
– The velocity–first or precision–first parameter for the
respective items is changed (including the [INIT] and
[G_INIT] soft keys).
4 If a parameter corresponding to a certain effective value is
changed, the parameter value may differ from a value
obtained from the velocity–first level, precision–first level, or
the current precision level.
5 The velocity–first or precision–first parameter group,
whichever is selected with the cursor, for the currently
displayed axis can be changed at a time by pressing:
[G_INIT] R [EXEC].
6 Entering values on the machining parameter tuning screen
or precision level select screen causes automatic
proportional allotment to be performed for the parameter to
be tuned. If the automatic proportional allotment fails,
leading to an incorrect calculation result, a waning message
meaning that automatic setting has failed appears.
7 On the machining condition select function screen, an
independent PMC axis can be neither displayed nor tuned.
The precision level can be changed not only on the precision level select
screen but also using the following program.
G05. 1 Q1 Rx; (level selecting, using an AI contour control or
AI–APC mode command)
G08 P1 Rx; (level selecting, using an APC mode command)
x...Level (1 to 10)
NOTE
Once the precision level is specified, it remains in effect
even when the AI contour control, AI–APC, and APC modes
are canceled.
Changing the precision
level, using a program
