B–64113EN–1/01

14. MEASUREMENT

961

IGX When the high-speed skip function is used, SKIP (bit 7 of X004), SKIPP

(bit 6 of G006), and +MIT1 to –MIT2 (bits 2 to 5 of X004) are:

0 : Enabled as skip signals.

1 : Disabled as skip signals.

NOTE

SKIPP (bit 6 of G006) and +MIT1 to –MIT2 (bits 2 to 5 of

X004) are enabled only when bit 0 (GSK) of parameter No.

6200 is set to 1 and bit 3 (MIT) of parameter No. 6200 is set

to 1. Note also that these signals are enabled only for the

T series.

6202

#6 #5 #4 #3 #2 #1 #0

1S1

1S1 For the G31 skip signal:

0 : The skip signal HDI0 is disabled.

1 : The skip signal HDI0 is enabled.

NOTE

HDI0 is high-speed skip signal.

CONNECTION MANUAL (Hardware)

(B–64113EN)

5.3

CONNECTING THE HIGH–SPEED SKIP

(HDI)

In a block specifying P1 to P4 after G31, the multi-step skip function

stores coordinates in a custom macro variable and cancels the remaining

distance that the block was supposed to be moved when a skip signal (8

points) or high-speed skip signal (4 points) is turned on.

Also in a block specifying Q1 to Q4 after G04, this function skips a dwell

when the skip signal or high speed skip signal has turned on.

A skip signal from equipment such as a fixed-dimension size measuring

instrument can be used to skip programs being executed.

In plunge grinding, for example, a series of operations from rough

machining to spark-out can be performed automatically by applying a

skip signal each time rough machining, semi-fine machining, fine-

machining, or spark-out operation is completed.

Reference item

14.3.3

Multi–step Skip

General
