0i/0i Mate - Model C Connection manual (Function) Page 40

Connection manual (Function)
B–64113EN–1/01
1. AXIS CONTROL
22
Place the controlled axes in the servo off state, stop the current to the servo
motor, which disables position control. However, the position detection
feature functions continuously, so the current position is not lost.
These signals are used to prevent the servo motors from overloading when
the tools on the axes are mechanically clamped under certain machining
conditions on the machine, or to move the machine by driving the motors
by mechanical handles.
[Classification] Input signal
[Function] Select whether to place each axis in the servo off state.
These signals are provided for the controlled axes on a single axis basis.
A number appended to a signal represents a controlled axis number.
1 ..... Servo off for the first axis
2 ..... Servo off for the second axis
3 ..... Servo off for the third axis
::
::
SVF 1
[Operation] These signals put the axes for which the signals are 1 in the servo off state
(the current to the servo motor is stopped). This disables position control.
However, the position detection feature continues to function, so the
current position is not lost.
#7 #6 #5 #4 #3 #2 #1 #0
G126 SVF4 SVF3 SVF2 SVF1
1.2.8
Servo Off
(Mechanical Handle)
General
Signal
Servo off signal
SVF1 – SVF4
<G126#0–#3>
Signal address
