0i/0i Mate - Model C Connection manual (Function) Page 1203

Connection manual (Function)
B–64113EN–1/01
A. INTERFACE BETWEEN CNC AND PMC
1185
Address
Referen
ce Item
M
series
T
series
Symbol Signal name
G007#6 Stored stroke limit select signal EXLM f f
2.3.2
G007#7 Stroke limit release signal RLSOT – f
2.3.2
G008#0 Interlock signal *IT f f
2.5
G008#1 Cutting block start interlock signal *CSL f f
2.5
G008#3 Block start interlock signal *BSL f f
G008#4 Emergency stop signal *ESP f f 2.1
G008#5 Feed hold signal *SP f f 5.1
G008#6 Reset & rewind signal RRW f f
5.2
G008#7 External reset signal ERS f f
5.2
G009#0 to 4 Workpiece number search signal
PN1,PN2,PN4,
PN8,PN16
f f 15.3
G010,G011 Manual feedrate override signal *JV0 to *JV15 f f 3.1
G012 Feedrate override signal *FV0 to *FV7 f f 7.1.7.2
G014#0,#1 Rapid traverse override signal ROV1,ROV2 f f 7.1.7.1
G016#7 F1-digit feed select signal F1D – f 7.1.5
G018#0 to #3
Manual handle feed axis selection signal
HS1A to HS1D f f
3.2
G018#4 to #7
Manual handle feed axis selection signal
HS2A to HS2D f f
3.2
G019#0 to #3 HS3A to HS3D f f
3.2
G019#4,#5
Manual handle feed amount selection signal (incremental
feed signal)
MP1,MP2 f f
G019#7 Manual rapid traverse selection signal RT f f 3.1
G023#5 In–position check disable signal NOINPS f f 7.2.5.3
G024#0 to G025#5 Expanded workpiece number search signals EPN0 to EPN13 f f
15.3.2
G025#7 Expanded workpiece number search start signal EPNS f f
15.3.2
G027#0
Spindle selection signal
SWS1 f f
9.9
G027#1
Spindle selection signal
SWS2 f f
9.9
G027#2 SWS3 f f
G027#3
Stop signal in each spindle
*SSTP1 f f
9.9
G027#4
Stop signal in each spindle
*SSTP2 f f
9.9
G027#5 *SSTP3 f f
G027#7 Cs contour control switch signal CON f f 9.8.1
G028#1,#2 Gear selection signal (input) GR1,GR2 f f 9.3
G028#4 Spindle unclamp completion signal *SUCPF f –
9.7
G028#5 Spindle clamp completion signal *SCPF f –
9.7
G028#6 Spindle stop completesignal SPSTP f –
G028#7 2nd position coder selection signal PC2SLC f –
9.9
G029#0 Gear select signal (input) GR21 f f
9.9
