0i/0i Mate - Model C Connection manual (Function) Page 1089

Connection manual (Function)
B–64113EN–1/01
16. INTERFACE WITH THE POWER MATE CNC
1071
#7
GR712330
#6
GR6
#5
GR5
#4
GR4
#3
GR3
#2
GR2
#1
GR1
#0
GR0
GRF12331 GRE GRD GRC GRB GRA GR9 GR8
[Data type] Bit
GR0 When group 0 (channel 1) of the PMC is a Power Mate or I/O Link β,
pulses of a manual pulse generator connected via the I/O Link are:
0 : Transferred to the target group.
1 : Not transferred to the target group.
GR1 When group 1 (channel 1) of the PMC is a Power Mate or I/O Link β,
pulses of a manual pulse generator connected via the I/O Link are:
0 : Transferred to the target group.
1 : Not transferred to the target group.
::
::
GRE When group 14 (channel 1) of the PMC is a Power Mate or I/O Link β,
pulses of a manual pulse generator connected via the I/O Link are:
0 : Transferred to the target group.
1 : Not transferred to the target group.
GRF When group 15 (channel 1) of the PMC is a Power Mate or I/O Link β,
pulses of a manual pulse generator connected via the I/O Link are:
0 : Transferred to the target group.
1 : Not transferred to the target group.
NOTE
When a Power Mate is connected to the I/O Link, set this
parameter to 1.
[Classification] CNC (host) → Servo amplifier unit
[Function] The signals select an operation mode of the b servo unit.
[Operation] The manual handle feed mode of the b servo unit is selected with the
signals.
Input signal
MD4 MD2 MD1
1 0 0 Handle feed
Signal (on the b servo
unit side)
Mode selection signals
MD1, MD2, MD4
<Yy+0#0, #1, #2>
