9. SPINDLE SPEED FUNCTION

618

For rigid tapping adjustment, the diagnosis screen displays information

related to rigid tapping.

For part of the display data, the user can choose between two sets of data

items relating to the synchronization of the spindle and tapping axis by

setting bit 0 (DGN) of parameter No. 5204.

The following information items are always displayed, regardless of the

setting of bit 0 (DGN) of parameter No. 5204:

· Spindle position deviation → Diagnosis No. 450

· Number of command pulses distributed to the spindle

(momentary value) → Diagnosis No. 451

· Cumulative number of command pulses distributed to the spindle

→ Diagnosis No. 454

When bit 0 (DGN) of parameter No. 5204 is set to 0, the following items

of information are displayed.

(Diagnosis Nos. 452 and 453 are not displayed.)

· Spindle–converted move command difference → Diagnosis No. 455

· Spindle–converted position deviation difference → Diagnosis No. 456

· Synchronization error range → Diagnosis No. 457

Spindle–converted move command difference

spindle move command (tapping axis move command) 4096

gear ratio thread lead

= Σ

Spindle–converted position deviation difference

spindle position deviation (tapping axis position deviation) 4096

gear ratio

thread lead

Synchronization error range

= (maximum spindle–converted move position deviation difference on

the positive side)

– (maximum spindle–converted position deviation difference on the

negative side)

If a maximum allowable synchronization error range is set in parameter

No. 5214, the position deviation alarm during spindle movement (alarm

No. 741) is issued to indicate that the set synchronization error range has

been exceeded. (If 0 is set in parameter No. 5214, no check is performed

to detect whether the synchronization error range has been exceeded.)

When bit 0 (DGN) of parameter No. 5204 is set to 1, the following items

of information are displayed. (Diagnosis Nos. 455, 456, and 457 are not

displayed.)

⋅ Momentary error difference between the spindle and tapping axis

→ Diagnosis No. 452

⋅ Maximum error difference between the spindle and tapping axis

→ Diagnosis No. 453

9.10.4

Display Data on the

Diagnosis Screen

D Common display data

D Display of rigid tapping

synchronization error

(When DGN = 0)

D Rigid tapping error

display

(error difference display)

(When DGN = 1)
