0i/0i Mate - Model C Connection manual (Function) Page 788

Connection manual (Function)
11. PROGRAM COMMAND
B–64113EN–1/01
770
5140 Minimum depth of cut in multiple repetitive canned cycle G76
[Data type] Two–word
Increment system IS-B IS-C Unit
Metric input 0.001 0.001 mm
Inch input 0.0001 0.0001 inch
[Valid data range] 0 to 99999999
This parameter sets the minimum depth of cut in multiple repetitive
canned cycle G76.
5141 Finishing allowance in multiple repetitive canned cycle G76
[Data type] Two–word
Increment system IS-B IS-C Unit
Metric input 0.001 0.001 mm
Inch input 0.0001 0.0001 inch
[Valid data range] 0 to 99999999
This parameter sets the finishing allowance in multiple repetitive canned
cycle G76.
5142 Repetition count of final finishing in multiple repetitive canned cycle G76
[Data type] Two–word
[Unit of data] Cycle
[Valid data range] 1 to 99999999
This parameter sets the repetition count in multiple repetitive canned
cycle G76.
5143 Tool nose angle in multiple repetitive canned cycle G76.
[Data type] Two–word
[Unit of data] Degree
[Valid data range] 0 to 120 when FS10/11 tape format is used
0, 29, 30, 55, 60 and 80 when FS10/11 tape format is not used.
This parameter sets the tool nose angle in multiple repetitive canned cycle
G76.
D Minimum depth of cut in
multiple repetitive
canned cycle G76
[Unit of data]
D Finishing allowance in
multiple repetitive
canned cycle G76
[Unit of data]
D Repetition count of final
finishing in multiple
repetitive canned cycle
G76
D Tool nose angle in
multiple repetitive
canned cycle G76.
