0i/0i Mate - Model C Connection manual (Function) Page 814

Connection manual (Function)
11. PROGRAM COMMAND
B–64113EN–1/01
796
5164 Percentage of the spindle speed to be changed when the tool is retracted after an
overload torque signal is received
[Data type] Byte
[Unit of data] %
[Valid data range] 0 to 255
This parameter sets the percentage of the spindle speed change caused by
the overload torque signal when the tool is retracted during a peck drilling
cycle.
S2 = S1 d1 B 100
S1: Spindle speed to be chaged
S2: Spindle speed changed
d1 is set as a percentage.
5165 Percentage of the spindle speed to be changed when the tool is retracted without
an overload torque signal received
[Data type] Byte
[Unit of data] %
[Valid data range] 0 to 255
This parameter sets the percentage of the spindle speed change during a
peck drilling cycle.
S2 = S1 d2 B 100
S1: Spindle speed to be chaged
S2: Spindle speed changed
d2 is set as a percentage.
5166 Percentage of cutting feedrate to be changed when the tool is retracted after an
overload torque signal is received
[Data type] Byte
[Unit of data] %
[Valid data range] 0 to 255
This parameter sets the percentage of the cutting feedrate change caused
by the overload torque signal during a peck drilling cycle.
F2 = F1 b1 B 100
F1: Cutting feedrate to be changed
F2: Changed cutting feedrate
b1 is set as a percentage.
