A. INTERFACE BETWEEN CNC AND PMC
1161
Function Section
M
series
T
series
AddressSymbolSignal name
Stored stroke check
Stored stroke limit switching signals in
axis direction
+EXL1 to +EXL4 G104 f f
2.3.2
Stored stroke check
Stored stroke limit switching signals in
axis direction
–EXL1 to –EXL4 G105 f f
2.3.2
Stored stroke check
Stored stroke limit change signal EXLM G007#6 f f
2.3.2
Stored stroke check
Stroke limit external setting signals
+LM1 to +LM4 G110 — f
2.3.2
Stored stroke check
Stroke limit external setting signals
–LM1 to –LM4 G110 — f
2.3.2
Stroke limit release signal RLSOT G007#7 — f
Stroke limit reached signals
+OT1 to +OT4 F124 — f
Stroke limit reached signals
–OT1 to –OT4 F126 — f
Stored stroke limit
2, 3
Stroke limit 3 release signal RLSOT3 G007#4 f f
2.3.3
Stored stroke limit Overtravel alarm in–progress signal OTP1 to OTP4 F124#0 to #3 f f
2.3.1
Absolute position
detection
Absolute position detector battery
voltage zero alarm signal
PBATZ F172#6 f f
1.4.2
Absolute position
detection
Absolute position detector battery
voltage low alarm signal
PBATL F172#7 f f
1.4.2
Controlled axis
detach
Controlled axis detach signals DTCH1 to DTCH4 G124#0 to #3 f f
1.2.4
Controlled axis
detach
Controlled axis detach status signals MDTCH1 to MDTCH4 F110#0 to #3 f f
1.2.4
Advanced preview Advanced preview control mode signal G08MD F066#0 f f
7.1.12
Software operator’s
Software operator’s panel signal (MD1) MD1O F073#0 f f
12.1.14
Software operator’s
Software operator’s panel signal (MD2) MD2O F073#1 f f
12.1.14
Software operator’s
Software operator’s panel signal (MD4) MD4O F073#2 f f
12.1.14
Software operator’s
Software operator’s panel signal (ZRN) ZRNO F073#4 f f
12.1.14
Software operator’s
Software operator’s panel signals
(+J1 to +J4)
+J1O to +J4O
F081#0, #2, #4,
#6
f f
12.1.14
Software operator’s
Software operator’s panel signals
(–J1 to –J4)
–J1O to –J4O
F081#1, #3, #5,
#7
f f
12.1.14
Software operator’s
Software operator’s panel signal (RT) RTO F077#6 f f
12.1.14
Software operator’s
Software operator’s panel signal
(HS1A)
HS1AO F077#0 f f
12.1.14
Software operator’s
panel
Software operator’s panel signal
(HS1B)
HS1BO F077#1 f f
12.1.14
Software operator’s panel signal
(HS1C)
HS1CO F077#2 f f
Software operator’s panel signal
(HS1D)
HS1DO F077#3 f f
Software operator’s panel signal
(MP1)
MP1O F076#0 f f
Software operator’s panel signal
(MP2)
MP2O F076#1 f f
Software operator’s panel signals (*JV0
to *JV15)
*JVO0 to *JV15O F079, F080 f f
Software operator’s panel signals
(*FV0 to *FV7)
*FV0O to *FV7O F078 f f
