0i/0i Mate - Model C Connection manual (Function) Page 1013

Connection manual (Function)
B–64113EN–1/01
15. PMC CONTROL FUNCTION
995
Axis control
command
(hexadecimal
code)
Operation
02h
Cutting feed – feed per revolution (exponential acceleration/
deceleration or linear acceleration/deceleration after inter-
polation)
02h
Performs the same operation as G95 G01, used by the
CNC.
03h
Skip – feed per minute
03h
Performs the same operation as G31 G01, used by the
CNC.
04h
Dwell
04h
Performs the same operation as G04, used by the CNC.
05h
Reference position return
05h
Moves the tool in the direction of reference position return
specified by ZMIx, bit 5 of parameter No. 1006, in rapid tra-
verse mode, then performs the same operation as manual
reference position return, done by the CNC.
06h
Continuous feed (exponential acceleration/deceleration)
06h
Moves the tool in the specified direction in jog feed mode.
Performs the same operation as that of JOG feed, done by
the CNC.
07h
1st reference position return
07h
Performs the same operation as done when positioning the
tool to the reference position from the intermediate point
specified by G28 of the CNC.
08h
2nd reference position return
08h
Performs the same operation as done when positioning the
tool to the reference position from the intermediate point
specified by G30 P2 of the CNC.
09h
3rd reference position return
09h
Performs the same operation as done when positioning the
tool to the reference position from the intermediate point
specified by G30 P3 of the CNC.
0Ah
4th reference position return
0Ah
Performs the same operation as done when positioning the
tool to the reference position from the intermediate point
specified by G30 P4 of the CNC.
0Bh
External pulse synchronization – main spindle
0Bh
Synchronizes with the main spindle.
0Dh
External pulse synchronization – 1st manual handle
0Dh
Synchronizes with the 1st manual handle.
