13. INPUT/OUTPUT OF DATA

B–64113EN–1/01

932

[Classification] Input signal

[Function] This signal specifies whether those signals that are shared by the external

I/O device control function are to be used with data input/output function

B based on the I/O Link.

[Operation] When this signal is set to 1, the control unit operates as follows:

– The signals (EXRD, EXSTP, EXWT, RPBSY, RPALM, and BGEACT)

for the external I/O device control function are used with data

input/output function B based on the I/O Link.

NOTE

I/O Link specification signal IOLS is not used with the

ordinary data input/output function based on the I/O Link.

[Classification] Input signal

[Function] These signals specify the group number of the power mate CNC that acts

as a slave when data input/output function B based on the I/O Link is used.

[Operation] The group number of the power mate CNC that acts as a slave is specified

with the values of four digits binary code signals.

NOTE

Group number specification signals SRLNI0 to SRLNI3 are

not used with the ordinary data input/output function based

on the I/O Link.

[Classification] Output signal

[Function] This signal instructs the power mate CNC to perform data input/output

based on the I/O Link.

[Output condition] This signal is set to 1 in the following case:

– When data input/output is performed

I/O Link specification

signal

IOLS <G092#1>

Group number

specification signals

SRLNI0 to SRLNI3

<G091#0 to #3>

Slave I/O Link selection

signal

IOLNK <F177#0>
