0i/0i Mate - Model C Connection manual (Function) Page 895

Connection manual (Function)
B–64113EN–1/01
12. DISPLAY/SET/EDIT
877
13612
Acceleration change time when AI contour control is used (bell–shaped)
(precision level 1)
13613
Acceleration change time when AI contour control is used (bell–shaped)
(precision level 10)
[Data type] Byte
[Unit of data] msec
[Valid data range] 1 to 100
These parameters set an acceleration change time (bell–shaped) with
emphasis placed on speed (precision level 1) and an acceleration change
time (bell–shaped) with emphasis placed on precision (precision level 10)
in AI contour control.
13620
Permissible acceleration when advanced preview control, AI advanced preview
control, or AI contour control is used (precision level 1)
13621
Permissible acceleration when advanced preview control, AI advanced preview
control, or AI contour control is used (precision level 10)
[Data type] 2–word axis
Increment system Unit
Millimeter machine 0.001mm/sec
2
[Valid data range] 0 to 99999999
These parameters set a permissible acceleration with emphasis placed on
speed (precision level 1) and a permissible acceleration with emphasis
placed on precision (precision level 10) in advanced preview control, AI
advanced preview control, or AI contour control.
13622
Time constant of acceleration/deceleration after interpolation
(precision level 1)
13623
Time constant of acceleration/deceleration after interpolation
(precision level 10)
[Data type] Word axis
[Unit of data] msec
[Valid data range] See the description of parameter No. 1768.
[Unit of data]
