11. PROGRAM COMMAND

B–64113EN–1/01

792

There are two types of NC programs; those which, rarely changed, and

those that changed with every execution. These programs are created by

the custom macro.

The custom macro is an executable form of a part program created by a

machine tool builder that is stored in the CNC’s flash ROM. It is executed

from the flash ROM.

Features

(1) Since the program is stored in executable form program, the execution

speed is high. Machine time is then reduced, and precision is

improved.

(2) Since the program is stored in FLASH ROM, there is no lost of data of

battery failure or corruption. Reliability is improved.

(3) The stored program is not displayed on a program screen.

(4) The custom macro is stored in FLASH ROM.

(5) The user can call the macro without knowing the stored program. A

custom macro can be created and executed in the program edit

memory.

(6) An original screen can be created by using the graphic display or by

selecting screens by the soft key. The machine tool builder can extend

the control function by using such functions as machine program

creation and edit control, reader/punch interface control, and PMC

data read/write functions.

NOTE

When the macro executor is active, the order-made macro

cannot be specified.

Macro compiler/executer programming manual (B–61803E–1)

11.13

MACRO COMPILER/

EXECUTER

General

Note

Reference item
