12. DISPLAY/SET/EDIT
B–64113EN–1/01
836
NOTE
1 Only the modes shown below can be selected by soft
switches. When the mode for DNC operation is to be
required, then, all control switches for mode selection
should be on the machine operator’s panel or a
general–purpose soft switch should be used to select the
mode for DNC operation.
Soft switches available for mode selection
⋅ Manual data input
⋅ Automatic operation
⋅ Memory edit
⋅ Manual handle feed / incremental feed
⋅ Jog feed
⋅ Manual reference position return
2 Only one soft switch is available for the protection key. But,
four input signals are available for protection key (KEY1,
KEY2, KEY3 and KEY4). Generally, four input signals are
simultaneously turned to “1” or “0” according to the state of
the protection soft switch.
3 When the soft switch for feed hold is turned on, output signal
SPO is turned to “1”, and the PMC turns feed hold signal *SP
to “0”.
In contrast to the above, when the soft switch for feed hold
is turned off, output signal SPO is turned ”0” and the PMC
turns signal *SP to “1”. For soft switches other than feed
hold and general soft switches, when an output signal
corresponding to a soft switch is turned to “1”, the
corresponding input signal is turned to “1”.
