0i/0i Mate - Model C Connection manual (Function) Page 171

Connection manual (Function)
B–64113EN–1/01
2. PREPARATIONS FOR OPERATION
153
Symbol Description
TZ Z–axis coordinate of a tailstock
L Length of a tailstock
D Diameter of a tailstock (diameter input)
L1 Length of a tailstock (1)
D1 Diameter of a tailstock (1) (diameter input)
L2 Length of a tailstock (2)
D2 Diameter of a tailstock (2) (diameter input)
D3 Diameter of the hole of a tailstock (diameter input)
TZ: Specifies the position (point B) of a tailstock with the Z–axis coordinate
of the workpiece coordinate system. In this case, do not use the coordinate
of the machine coordinate system. The profile of a tailstock is assumed to
be symmetrical with respect to the Z–axis.
WARNING
Specifying the position of a tailstock with a radius or
diameter depends on whether the Z–axis conforms to
radius or diameter specification.
L, L1, L2, D, D1, D2, and D3:
Define the profile of a tailstock.
WARNING
D, D1, D2, and D3 are always specified with diameters. L,
L1, and L2 are also specified with radii whenever the Z–axis
conforms to radius specification.
Number Message Description
502
OVER TRAVEL : +X The tool has entered the forbidden
area when moving in the positive
direction along the X–axis.
OVER TRAVEL : +Z The tool has entered the forbidden
area when moving in the positive
direction along the Z–axis.
503
OVER TRAVEL : –X The tool has entered the forbidden
area when moving in the negative
direction along the X–axis.
OVER TRAVEL : –Z The tool has entered the forbidden
area when moving in the negative
direction along the Z–axis.
Alarm and message
Previous page
Next page
