0i/0i Mate - Model C Connection manual (Function) Page 1181

Connection manual (Function)
B–64113EN–1/01
A. INTERFACE BETWEEN CNC AND PMC
1163
Function Section
M
series
T
series
AddressSymbolSignal name
General purpose
retract
Retract signal RTRCT G066#4 f f
1.9
General purpose
retract
Retract completion signal RTRCTF F065#4 f f
1.9
Direct operation by
PMC/Open CNC
Direct operation selection signal DMMC G042#7 f f
15.6
PMC axis control
Control axis selection signals
(PMC axis control)
EAX1 to EAX4 G136 f f
15.1
PMC axis control
Axis control superimposed command
signal
EASIP1 to EASIP4 G200 f f
15.1
PMC axis control
Axis control command signals
EC0A to EC6A G143#0 to #6 f f
15.1
PMC axis control
Axis control command signals
(PMC axis control)
EC0B to EC6B G155#0 to #6 f f
15.1
PMC axis control
Axis control command signals
(PMC axis control)
EC0C to EC6C G167#0 to #6 f f
15.1
PMC axis control
EC0D to EC6D G179#0 to #6 f f
15.1
PMC axis control
Axis control feedrate signals
EIF0A to EIF15A G144, G145 f f
15.1
PMC axis control
Axis control feedrate signals
(PMC axis control)
EIF0B to EIF15B G156, G157 f f
15.1
PMC axis control
Axis control feedrate signals
(PMC axis control)
EIF0C to EIF15C G168, G169 f f
15.1
PMC axis control
EIF0D to EIF15D G180, G181 f f
15.1
PMC axis control
Axis control command read signals
EBUFA G142#7 f f
15.1
PMC axis control
Axis control command read signals
(PMC axis control)
EBUFB G154#7 f f
15.1
PMC axis control
Axis control command read signals
(PMC axis control)
EBUFC G166#7 f f
15.1
PMC axis control
EBUFD G178#7 f f
15.1
PMC axis control
Axis control data signals
EID0A to EID31A G146 to G149 f f
15.1
PMC axis control
Axis control data signals
(PMC axis control)
EID0B to EID31B G158 to G161 f f
15.1
PMC axis control
Axis control data signals
(PMC axis control)
EID0C to EID31C G170 to G173 f f
15.1
EID0D to EID31D G182 to G185 f f
Axis control command read completion
EBSYA F130#7 f f
Axis control command read completion
signals (PMC axis control)
EBSYB F133#7 f f
Axis control command read completion
signals (PMC axis control)
EBSYC F136#7 f f
EBSYD F139#7 f f
Reset signals (PMC axis control)
ECLRA G142#6 f f
Reset signals (PMC axis control)
ECLRB G154#6 f f
Reset signals (PMC axis control)
ECLRC G166#6 f f
ECLRD G178#6 f f
Axis control temporary stop signals
ESTPA G142#5 f f
Axis control temporary stop signals
(PMC axis control)
ESTPB G154#5 f f
Axis control temporary stop signals
(PMC axis control)
ESTPC G166#5 f f
ESTPD G178#5 f f
Block stop signals (PMC axis control)
ESBKA G142#3 f f
Block stop signals (PMC axis control)
ESBKB G154#3 f f
Block stop signals (PMC axis control)
ESBKC G166#3 f f
ESBKD G178#3 f f
