0i/0i Mate - Model C Connection manual (Function) Page 1197

Connection manual (Function)

Page of 1224

/ 1224

B–64113EN–1/01

A. INTERFACE BETWEEN CNC AND PMC

1179

Group

Referen

ce item

series

Address Signal nameSymbol

PBATL

Absolute position detector battery voltage low alarm

signal

F172#7 f f

1.4.2

PBATZ

Absolute position detector battery voltage zero

alarm signal

F172#6 f f

1.4.2

PC1DTA

Signal indicatingthe status of the detected

one rotation position coder signal (serial spindle)

F047#0 f f

9 2

PC1DTB

Signal indicatingthe status of the detected

one-rotation position coder signal (serial spindle)

F051#0 f f

PC2SLC 2nd position coder selection signal G028#7 f f 9.9

PECK2 Small-diameterpeck drilling in progress signal F066#5 – f 11.14

PN1,PN2,PN4,PN8,

PN16

Workpiece number search signal G009#0 to 4 f f 15.3

PORA2A

Signal for approximatespindle orientationwith a

position coder (serial spindle)

F046#5 f f

9 2

PORA2B

Signal for approximatespindle orientationwith a

position coder (serial spindle)

F050#5 f f

PRC Position record signal G040#6 f – 14.4.1

PRGDPL program screen display mode signal F053#1 f f 15.5

PRTSF Target parts count reached signal F062#7 f f 12.1.11

PSAR Spindle polygon speed arrival signal F063#2 f –

6.10.2

PSE1 Master axis not arrival signal F063#0 f –

6.10.2

PSE2 Polygon synchronous axis not arrival signal F063#1 f –

PSW01 to PSW16 Position switch signal

F070#0 to

F071#7

f f 1.2.9

PSYN Polygon synchronization under way signal F063#7 f – 6.9.1

R01I to R12I

Spindle motor speed command signal

G032#0 to

G033#3

f f

15.4

R01I2 to R12I2

Spindle motor speed command signal

G034#0 to

G035#3

f f

15.4

R01I3 to R12I3

G036#0 to

G037#3

f f

R01O to R12O S12-bit code signal

F036#0 to

F037#3

f f 9.3

RCFNA

Output switch completion signal (serial spindle)

F046#3 f f

9.2

RCFNB

Output switch completion signal (serial spindle)

F050#3 f f

9.2

RCHA

Power line status check signal (serial spindle)

G071#7 f f

9.2

RCHB

Power line status check signal (serial spindle)

G075#7 f f

9.2

RCHHGA

High–output MCC status signal while a magnetic

sensor (serial spindle)

G072#7 f f

9.2

RCHHGB

High–output MCC status signal while a magnetic

sensor (serial spindle)

G076#7 f f

RCHPA

Output switch signal (serial spindle)

F046#2 f f

RCHPB

Output switch signal (serial spindle)

F050#2 f f

RGSPM

Spindle rotation direction signal

F065#1 – f

9.10

RGSPP

Spindle rotation direction signal

F065#0 – f

9.10

RGTAP Rigid tapping signal G061#0 f f

9.10

RGTSP1,RGTSP2 Rigid tapping spindle selection signal G061#4,#5 f –

RLSOT Stroke check release signal G007#7 – f 2.3.2

RLSOT3 Stroke check 3 release signal G007#4 f f 2.3.3
