0i/0i Mate - Model C Connection manual (Function) Page 691

Connection manual (Function)
B–64113EN–1/01
9. SPINDLE SPEED FUNCTION
673
Number Message Description
200 ILLEGAL S CODE COM-
MAND
In rigid tapping, an S value is out of the
range or is not specified.
The maximum value for S which can be
specified in rigid tapping is set in pa-
rameter (No.5241 to 5243). Change the
setting in the parameter or modify the
program.
201 FEEDRATE NOT FOUND
IN RIGID TAP
In rigid tapping, no F value is specified.
Correct the program.
202 POSITION LSI OVER-
FLOW
In rigid tapping, spindle distribution val-
ue is too large.
203 PROGRAM MISS AT RIG-
ID TAPPING
In rigid tapping, position for a rigid M
code (M29) or an S command is incor-
rect. Modify the program.
204 ILLEGAL AXIS OPERA-
TION
In rigid tapping, an axis movement is
specified between the rigid M code
(M29) block and G84 or G74 block for
M series (G84 or G88 block for T se-
ries). Modify the program.
205 RIGID MODE DI SIGNAL
OFF
1. Although a rigid M code (M29) is
specified in rigid tapping, the rigid
mode DI signal (DGN G061.0) is not
ON during execution of the G84
(G88) block.
2. In a system with the multi–spindle,
the spindle used for rigid tapping is
not selected (by DI signal G27#0
and #1, or G61#4 and #5 (T series
only).
Check the PMC ladder diagram to find
the reason why the DI signal is not
turned on.
206 CAN NOT CHANGE
PLANE (RIGID TAP)
Plane changeover was instructed in the
rigid mode.
Correct the program.
207 RIGID DATA MISMATCH The specified distance was too short or
too long in rigid tapping.
410 SERVO ALARM: n–TH
AXIS – EXCESS ERROR
The position deviation value when the
n–th axis (axis 1–4 of rigid tapping axis)
stops is larger than the set value.
Note) Limit value must be set to param-
eter No.5312 for each axis.
411 SERVO ALARM: n–TH
AXIS – EXCESS ERROR
The position deviation value when the
n–th axis (axis 1–4 of rigid tapping axis)
moves is larger than the set value.
Note) Limit value must be set to param-
eter No. 5310 or 5314 for each axis.
9.10.9
Alarm and Message
