0i/0i Mate - Model C Connection manual (Function) Page 858

Connection manual (Function)
12. DISPLAY/SET/EDIT
B–64113EN–1/01
840
[Data type] Bit
Select the language to be used for the display.
CH2 CZE SWE HUN POL POR DTH SPN HNG ITA CHI FRN GRM JPN Language
0 0 0 0 0 0 0 0 0 0 0 0 0 0 English
0 0 0 0 0 0 0 0 0 0 0 0 0 1 Japanese
0 0 0 0 0 0 0 0 0 0 0 0 1 0 German
0 0 0 0 0 0 0 0 0 0 0 1 0 0 French
0 0 0 0 0 0 0 0 0 0 1 0 0 0
Chinese
(traditional
characters)
0 0 0 0 0 0 0 0 0 1 0 0 0 0 Italian
0 0 0 0 0 0 0 0 1 0 0 0 0 0 Korean
0 0 0 0 0 0 0 1 0 0 0 0 0 0 Spanish
0 0 0 0 0 0 1 0 0 0 0 0 0 0 Dutch
0 0 0 0 0 1 0 0 0 0 0 0 0 0 Portuguese
0 0 0 0 1 0 0 0 0 0 0 0 0 0 Polish
0 0 0 1 0 0 0 0 0 0 0 0 0 0 Hungarian
0 0 1 0 0 0 0 0 0 0 0 0 0 0 Swedish
0 1 0 0 0 0 0 0 0 0 0 0 0 0 Czech
1 0 0 0 0 0 0 0 0 0 0 0 0 0
Chinese
(simplified
characters)
Parameter setting enables one external operator message (consisting of up
255 characters) or, simultaneously, up to 4 external operator message
(consisting of up to 63 characters) to be displayed.
External operator messages can be logged in a history file.
These messages can be displayed on the external operator message history
screen.
#7 #6 #5 #4 #3 #2 #1 #0
3112 OMH
[Data type] Bit
OMH The external operator message history screen is:
0 : Not displayed.
1 : Displayed.
12.1.16
External Operator
Message Logging and
Display
General
Parameter
