B–64113EN–1/01

A. INTERFACE BETWEEN CNC AND PMC

1174

Group

Referen

ce item

series

Address Signal nameSymbol

EMBUFA

Buffering disable signal

G142#2 f f

15.1

EMBUFB

Buffering disable signal

(PMC axis control)

G154#2 f f

15.1

EMBUFC

Buffering disable signal

(PMC axis control)

G166#2 f f

15.1

EMBUFD G178#2 f f

15.1

EMFA

Auxiliary function strobe signal (PMC axis control)

F131#0 f f

15.1

EMFB

Auxiliary function strobe signal (PMC axis control)

F134#0 f f

EMFC

Auxiliary function strobe signal (PMC axis control)

F137#0 f f

EMFD F140#0 f f

EMSBKA

Block stop disable signal

G143#7 f f

15.1

EMSBKB

Block stop disable signal

(PMC axis control)

G155#7 f f

15.1

EMSBKC

Block stop disable signal

(PMC axis control)

G167#7 f f

15.1

EMSBKD G179#7 f f

ENB

Spindle enable signal

F001#4 f f 9.3

ENB2

Spindle enable signal

F038#2 f –

9.9

ENB3 F038#3 f –

9.9

ENBKY External key input mode selection signal G066#1 f f 15.5

EOTNA

Negative direction overtravel signal (PMC axis

F130#6 f f

15.1

EOTNB

Negative

direction overtravel signal (PMC axis

control)

F133#6 f f

15.1

EOTNC

Negative direction overtravel signal (PMC axis

control)

F136#6 f f

15.1

EOTND F139#6 f f

15.1

EOTPA

Positive direction overtravel signal (PMC axis

F130#5 f f

15.1

EOTPB

Positive

direction overtravel signal (PMC axis

control)

F133#5 f f

EOTPC

Positive direction overtravel signal (PMC axis

control)

F136#5 f f

EOTPD F139#5 f f

EOV0 Override 0% signal (PMC axis control) F129#5 f f

EPARM Slave parameter selection signal F177#6 f f 13.5

EPN0 to EPN13 Expanded workpiece number search signals

G024#0 to

G025#5

f f

15.3.2

EPNS Expanded workpiece number search start signal G025#7 f f

15.3.2

EPRG Slave program selection signal F177#4 f f

13.5

ERDIO Slave external read start signal F177#1 f f

13.5

EREND Read completionsignal for external data input F060#0 f f 15.2

ERS External reset signal G008#7 f f 5.2

ESBKA

Block stop signal (PMC axis control)

G142#3 f f

15.1

ESBKB

Block stop signal (PMC axis control)

G154#3 f f

15.1

ESBKC

Block stop signal (PMC axis control)

G166#3 f f

15.1

ESBKD G178#3 f f

ESEND Search completion signal for external data input F060#1 f f 15.2
