4. REFERENCE POSITION ESTABLISHMENT

211

The tool is moved in the direction specified by parameter ZMI (bit 5 of

No. 1006) setting the feed axis and direction select signal to “1” during

manual reference position return mode. Movement will continue until the

reference position is obtained.

Manual reference position return is performed by using a grid method.

The reference position is based on an electrical grid, using on one–rota-

tion signals received from the position detector.

The following signals relate with the manual reference position return:

Manual Reference Position Return

Mode selection MD1, MD2, MD4

Selection of reference position return ZRN, MREF

Selection of axis to be moved

+J1, –J1, +J2, –J2, +J3, –J3, ...

Selection of direction to be moved

+J1, –J1, +J2, –J2, +J3, –J3, ...

Selection of speed to be moved ROV1, ROV2

Deceleration signal for reference

position return

*DEC1, *DEC2, *DEC3, ...

Completion signal for reference

position return

ZP1, ZP2, ZP3, ...

Reference position establishment

signal

ZRF1, ZRF2, ZRF3, ...

(1)Select JOG mode or TEACH IN JOG mode, and the manual reference

position return selection signal ZRN to “1”.

(2)Feed a target axis toward the reference position by setting an

appropriate feed axis and direction selection signal (+J1, –J1, +J2,

–J2,…) “1”.

(3)While the feed axis and direction selection signal is “1”, rapid traverse

takes place along that axis. Although the rapid traverse override

signals (ROV1, ROV2) are valid, the override is generally set to

100%.

(4)When the reference position is approached, a limit switch installed on

the machine is activated, making the deceleration signal (*DEC1,

*DEC2, *DEC3,…) for reference position “0”. Consequently, the

feedrate is decelerated to 0, then the tool is fed at a constant low speed

(reference position return FL feedrate specified by parameter (No.

1425) setting).

(5)When the deceleration signal returns to “1” again after the limit switch

is passed, the tool is continues to feed, until the tool stops at the first

grid point (electric grid point).

4.1

MANUAL

REFERENCE

POSITION RETURN

General

Basic Procedure for

Manual Reference

Position Return
