6. INTERPOLATION FUNCTION
327
Number DescriptionMessage
023 ILLEGAL RADIUS
COMMAND
(T series)
In circular interpolation by radius des-
ignation, negative value was com-
manded for address R. Modify the
program.
025 CANNOT COMMAND F0
IN G02/G03
(M series)
F0 (rapid traverse) was instructed by
F1 –digit command in circular inter-
polation. Modify the program.
028 ILLEGAL PLANE
SELECT
In the plane selection command, two
or more axes in the same direction
are commanded.
Modify the program.
5059 RADIUS IS OUT OF
RANGE
For circular interpolation, the radius
specified with addresses I and K ex-
ceeds the allowable range.
NOTE
1 For T series, the U, V and W axes (parallel with the basic
axis) can be used with G–code system B and C.
2 If I, J, K, and R addresses are specified simultaneously, the
arc specified by address R takes precedence and the other
are ignored.
3 If an axis not comprising the specified plane is commanded,
an alarm is displayed.
For example, when G code system B or C is used, if U axis
with X axis is specified as a parallel axis to X axis when
plane XY is specified, an P/S alarm (No.028)is displayed.
Series 0i–C
OPERATOR’S MANUAL
(M series) (B–64124EN)
II.4.4
CIRCULAR INTERPOLATION
(G02,G03)
Series 0i–C
OPERATOR’S MANUAL
(T series) (B–64114EN)
II.4.3
CIRCULAR INTERPOLATION
(G02,G03)
Series 0i Mate–C
OPERATOR’S MANUAL
(M series) (B–64144EN)
II.4.4
CIRCULAR INTERPOLATION
(G02,G03)
Series 0i Mate–C
OPERATOR’S MANUAL
(T series) (B–64134EN)
II.4.3
CIRCULAR INTERPOLATION
(G02,G03)
Note
Reference item
Previous page
Next page
