5. AUTOMATIC OPERATION

B–64113EN–1/01

306

#7 #6 #5 #4 #3 #2 #1 #0

G043

F003

DNCI

MRMT

#7 #6 #5 #4 #3 #2 #1 #0

0100 ND3

This parameter can be set at the “Setting Screen.”

[Data type] Bit

ND3 In DNC operation, a program is:

0 : Read block by block. (A “DC3” code is output for each block.)

1 : Read continuously until the buffer becomes full. (A “DC3” code is

output when the buffer becomes full.)

NOTE

In general, reading is performed more efficiently when

ND3=1. This specification reduces the number of buffering

interruptions caused by reading of a series of blocks

specifying short movements. This reduces the cycle time.

DNM0138

#6 #5 #4 #3 #2 #1 #0

[Data type] Bit

DNM DNC operation with a memory card is:

0 : Disabled.

1 : Enabled. (A PCMCIA card attachment is required separately.)

NOTE

1 It is necessary to secure the memory card by using a

PCMCIA card attachment suitable for the memory card

CNC.

2 While DNC operation using a memory card is being

performed, display of a directory in the memory card and

other operations that access to the memory card cannot be

performed.

3 A set DNC operation file name is erased at power–off.

4 During DNC operation using a memory card, do not remove

or insert the memory card.

5 A program executed in DNC operation cannot call a

program stored on the memory card.
