0i/0i Mate - Model C Connection manual (Function) Page 698

Connection manual (Function)

Page of 1224

/ 1224

B–64113EN–1/01

9. SPINDLE SPEED FUNCTION

680

5261 Time constant for the first spindle and tapping axis (first gear stage)

5262 Time constant for the first spindle and tapping axis (second gear stage)

5263 Time constant for the first spindle and tapping axis (third gear stage)

5265 Time constant for the second spindle and tapping axis (first gear stage)

5266 Time constant for the second spindle and tapping axis (second gear stage)

[Data type] Word

[Unit of data] msec

[Valid data range] 0 to 4000

The spindle and tapping axis time constant for each gear stage is set up

for rigid tapping.

The time needed for the spindle to reach its maximum permissible

rotation speed is specified. The actual time constant is the ratio of the

maximum permissible spindle speed to the S command.

If bell–shaped acceleration/deceleration is enabled, the time constant for

the straight section is set up.

5271

Time constant for the first spindle and tapping axis for a pull–out operation

(first gear stage)

5272

Time constant for the first spindle and tapping axis for a pull–out operation

(second gear stage)

5273

Time constant for the first spindle and tapping axis for a pull–out operation

(third gear stage)

5335

Time constant for the second spindle and tapping axis for a pull–out operation

(first gear stage)

5336

Time constant for the second spindle and tapping axis for a pull–out operation

(second gear stage)

[Data type] Word

[Unit of data] msec

[Valid data range] 0 to 4000

The spindle and tapping axis time constant for each gear stage is set up

for a rigid tapping pull–out operation.

If bell–shaped acceleration/deceleration is valid, the time constant for the

straight section is set up.

NOTE

These parameters are valid if the TDR parameter (bit 2 of

parameter No. 5201) is 1.
