0i/0i Mate - Model C Connection manual (Function) Page 453

Connection manual (Function)
B–64113EN–1/01
7. FEEDRATE CONTROL/ACCELERATION
AND DECELERATION CONTROL
435
Name Function
Automatic corner override (G62) f Set bit 0 (ACO) of parameter No. 7055 to 1.
Automatic corner deceleration f
Feedrate clamping by arc radius f
Scaling (G51) f
Coordinate system rotation (G68) f
Programmable mirror image
(G51.1)
f
F10/11 tape format f
Auxiliary functions/spindle–speed functions
f : Can be specified. : Cannot be specified.
Name Function
Miscellaneous function (Mxxxx) f The function code and function strobe signals
are output only.
Second auxiliary function (Bxxxx) f The function code and function strobe signals
are output only.
High–speed M/S/T/B interface f
Multiple miscellaneous function
specification
f
Spindle–speed function (Sxxxx) f
Spindle synchronous control f
Rigid tapping f (*2)
Set bit 5 (G8S) of parameter No. 1602 or bit 3
(ACR) of parameter No. 7051 to 1.
Tool compensation functions
f : Can be specified. : Cannot be specified.
Name Function
Tool function (Txxxx) f The function code and function strobe signals
are output only.
Tool offset memory C f
Tool length compensation
(G43, G44, G49)
f
Tool offset (G45 to G48)
Cutter compensation C
(G40, G41, G42)
f
Tool life management
Automatic tool length measure-
ment
Other functions f : Can be specified. : Cannot be specified.
Name Function
Cycle start/feed hold f
Dry run f
Single block f
Sequence number comparison
and stop
f
Program restart f For the time constant for acceleration/decelera-
tion during movement to the restart position,
the following parameters are used:
When exponential acceleration/deceleration is
used: Parameter Nos. 1624 and 1625
When linear/bell–shaped acceleration/decel-
eration is used: Parameter No. 1622
To set the acceleration/deceleration type, use
bits 0 and 1 of parameter No. 1610.
