0i/0i Mate - Model C Connection manual (Function) Page 1090

Connection manual (Function)
16. INTERFACE WITH THE POWER MATE CNC
B–64113EN–1/01
1072
NOTE
1 Turn the manual pulse generator after placing it in the
manual handle mode.
2 Do not switch between the modes during manual handle
operation of the b servo unit.
[Classification] CNC (host) → Servo amplifier unit
[Function] The signals select a magnification for the manual handle.
[Operation] The b servo unit drives the motor in the manual handle mode by the pulses
obtained by multiplying the number of input pulses of the manual pulse
generator by a magnification set by the signals.
Input signal
Amount of travel per division of the manual
pulse generator
MP2 MP1
pulse generator
0 0 1 user unit
0 1 10 user units
1 0 100 user units
1 1 (M/N) user units
(M = Parameter No. 62, N = Parameter No. 63)
NOTE
1 The signals are valid when bit 5 (MP) of parameter No. 5 for
the b servo unit is set to 1.
2 The signals are valid only in the manual handle mode.
3 The signals are used also as rapid traverse override signals.
In the manual handle mode, the signals function as the
incremental feed signals. In modes other than the manual
handle mode, the signals function as the rapid traverse
override signals. When the mode is switched from the
manual handle mode to another mode, the setting of the
signals need to be returned to the setting of the rapid
traverse override signals.
#7
Yy+0
#6 #5 #4 #3 #2
MD4
#1
MD2
#0
MD1
#7
Yy+7
#6 #5
MP2
#4
MP1
#3 #2 #1 #0
Incremental feed signals
MP1, MP2 <Yy+7#4, #5>
Signal address
