0i/0i Mate - Model C Connection manual (Function) Page 1129

Connection manual (Function)
B–64113EN–1/01
18. TROUBLE DIAGNOSIS
1111
8860 Trouble forecast level for thermal simulation
8861 Trouble forecast level for disturbance torque
[Data type] WORD AXIS
[Unit of data] %
[Valid data range] 0 to 100%
#7
13110
#6 #5 #4 #3 #2 #1 #0
JPN
NOTE
When this parameter is set, the power must be turned off
before operation is continued.
[Data type] Bit
JPN As the display language used for trouble diagnosis and machine alarm
diagnosis:
0 : English has precedence.
For machine alarm diagnosis, the GUIE_USR.MEM file has
precedence.
1 : Japanese has precedence.
For machine alarm diagnosis, the GUIJ_USR.MEM file has
precedence.
[Classification] Output signal
[Output condition] When thermal simulation or disturbance torque of servo axis exceeds the
trouble forecast level, TDFSVx turn to 1.
Signal
Trouble forecast signal
TDF1 to TDF7 <F0298>
