15. PMC CONTROL FUNCTION
B–64113EN–1/01
1002
[Valid data range] Specify data within the range given in the following table.
Data range
Unit
IS-B IS-C
Unit
Linear
axis
Metric machine 30 to 15000 30 to 12000 mm/min
Linear
axis
Inch machine 30 to 6000 30 to 4800 inch/min
Rotation axis 30 to 15000 30 to 12000 deg/min
(7) Cutting feed – feed per minute (EC0g to EC6g: 01h)
(8) Skip – feed per minute (EC0g to EC6g: 03h)
For these commands, the signals are used to specify, in binary
format, the feedrate along an axis. The specified feedrate can be
magnified by ten by the setting of bit 3 (F10) of parameter No. 8002.
[Unit of data] When bit 3 (F10) of parameter No. 8002 is set to 0
Data unit
Unit
IS–B IS–C
Unit
Linear
axis
Metric machine 1 0.1 mm/min
Linear
axis
Inch machine 0.01 0.001 inch/min
Rotation axis 1 0.1 deg/min
When bit 3 (F10) of parameter No. 8002 is set to 1
Data unit
Unit
IS–B IS–C
Unit
Linear
axis
Metric machine 10 1 mm/min
Linear
axis
Inch machine 0.1 0.01 inch/min
Rotation axis 10 1 deg/min
[Valid data range] 1 to 65535
(Actual values must fall within the ranges given in the following table.)
Data range
Unit
IS–B IS–C
Unit
Linear
axis
Metric machine 1 to 100000 0.1 to 12000.0 mm/min
Linear
axis
Inch machine 0.01 to 4000.00 0.001 to 480.000 inch/min
Rotation axis 1 to 100000 0.1 to 12000.0 deg/min
CAUTION
When “0” is specified, the CNC continues to perform
buffering without moving the tool. In such a case, release
the buffering by issuing reset signal ECLRg.
Cutting feedrate clamp is disabled.
