0i/0i Mate - Model C Connection manual (Function) Page 977

Connection manual (Function)

Page of 1224

/ 1224

B–64113EN–1/01

14. MEASUREMENT

959

P : Distance to be measured [mm/inch]

Q : Servo delay [mm/inch]

Under the conditions shown above, the NC calculates the following

equation using parameter SEA (bit 0 of parameter No. 6201) or SEB (bit

1 of parameter No. 6201):

P = Pnc – Q

For type A (SEA bit 0 of parameter No. 6201 is “1”), the deviation is

calculated by:

Q = Fm 1/60 (a Tc/1000 + Ts/1000)

where

Fm : Feedrate [mm/min or inch/min]

Tc : Cutting time constant [msec]

Parameter No. 1622: Exponential acceleration/deceleration

Parameter No. 1628: Linear acceleration/deceleration after

interpolation

If parameter SKF (bit 7 of parameter No. 6200) = 0, Tc = 0.

Ts : Servo time constant [msec]

Assuming that the loop gain (parameter No. 1825) is G (unit: 1/s):

Ts = 1000/G

α : = 1 Exponential acceleration/deceleration

= 1/2 Linear acceleration/deceleration after interpolation

NOTE

For type A (parameter SEA (No. 6201 #0)=1), the skip signal

must be turned on when the tool moves at constant

feedrate.
