B–64113EN–1/01

4. REFERENCE POSITION ESTABLISHMENT

257

WARNING

If you set parameter 1818#3 (SDCx), please don’t forget to

turned off before operation is continued. This parameter

doesn’t generate P/S alarm 0 (Power–off alarm).

1819

#6 #5 #4 #3 #2

DAT

#1 #0

[Data type] Bit axis

DATx When manual reference point return is executed, the automatic setting of

paramete 1883,1884 is:

0 : Not executed.

1 : Executed.

The procedure of the automatic setting are following :

(1)Set a correct value to parameter No.1815,1821,1882.

* On the linear scale with distance–coded reference marks (serial),

parameter No.1882 is unnecessary to set.

(2)Positioning the axis to reference position by mechanical measurement

by manual operation.

(3)Execute manual reference point return.

When the manual reference point return is finished, parameter

No.1883,1884 are set and No.1819#2 is turn to ’0’.

1821 Reference counter size for each axis

[Data type] 2–word axis

[Unit of data] Detection unit

[Valid data range] 0 to 99999999

Sets the intervals of mark 1 of the linear scale with abssolute addressing

referenced marks.

CAUTION

On the linear scale with distance–coded reference marks

(A/B phase), this parameter is used on the usual purpose.

(Setting reference counter size foreach axis)

1882

Space between mark–2 indications on the linear scale with absolute

addressing reference marks

[Data type] 2–word axis

[Unit of data] Detection unit

[Valid data range] 0 to 99999999

Sets the intervals of mark 1 of the linear scale with abssolute addressing

referenced marks.
