B–64113EN–1/01

11. PROGRAM COMMAND

781

#7 #6 #5 #4 #3 #2 #1 #0

IDX5500 SIM G90 INC ABS REL DDP

[Data type] Bit

DDP Definition of index values

0 : Conventional method (Example IS–B: B1; = 0.001 deg)

1 : Calculator method (Example IS–B: B1; = 1.000 deg)

REL Relative position display of index table indexing axis

0 : Not rounded by 360 degrees

1 : Rounded by 360 degrees

ABS Displaying absolute coordinate value of index axis

0 : Not rounded by 360 degrees

The index axis rotates 720 degrees (two rotations) when G90 B720.0;

is specified from the 0–degree position. It rotates in reverse direction

720 degrees (two rotations) when G90 B0.; is specified. The absolute

coordinate value then becomes 0 degree.

1 : Rounded by 360 degrees

The index axis is positioned to 40 degrees when G90 B400.0; is

specified from the 0–degree position. The index axis does not rotate

by two or more turns when this parameter is set to 1. It also does not

move when G90 B720.0; is specified from the 0–degree position.

INC Rotation in the G90 mode. This applies when negative direction M–code

(parameter No. 5511) is not set

0 : Not set to the shorter distance around the circumference

1 : Move the shorter distance around the circumference (Set ABS, #2 of

parameter No. 5500, to 1.)

G90 Index table indexing command

0 : An absolute/increment command according to the G90/G91 mode

1 : Always an absolute command

SIM When the same block includes a command for an index table indexing

axis and a command for another controlled axis:

0 : A P/S alarm (No.136) is issued.

1 : The commands are executed. (In a block other than G00, G28, and

G30, however, a P/S alarm (No.136) is issued.)

IDX Index table indexing sequence

0 : Type A

1 : Type B

#7 #6 #5 #4 #3 #2 #1 #0

5501 ITI

[Data type] Bit

ITI The index table index function is:

0 : Enabled.

1 : Disabled.

D Setting for positioning

the index table

D The parameter specifies

whether the index

table index

function is

disabled.
