B–64113EN–1/01

1. AXIS CONTROL

All the compensation data can be displayed and set on the conventional

screen for the pitch error compensation data.

And those data can be input and output by the following methods.

* Input by MDI

* Input by G10

* Input and output by input/output device interface

* Input by PMC window (function code 18)

(It is not possible to input and output by the method other than the

above methods.)

Output format : The output format is as follows:

N20000 P.... ;

N21023 P.... ;

N23000 P.... ;

N24023 P.... ;

N : Pitch error compensation point No. + 20000

P : Pitch error compensation data

3605

#6 #5 #4 #3 #2 #1 #0

BDP

[Data type] Bit axis

BDP Specifies whether to use bidirectional pitch error compensation.

0 : Do not use.

1 : Use.

NOTE

When this parameter is set, the power must be turned off

before operation is continued.

3620

Number of the pitch error compensation position for the reference position for each

axis

[Data type] Word axis

[Unit of data] Number

[Valid data range] 0 to 1023, 3000 to 4023

Set the number of the pitch error compensation position for the reference

position for each axis

NOTE

When this parameter is set, the power must be turned off

before operation is continued.

Setting and displaying

data

Parameter
