0i/0i Mate - Model C Connection manual (Function) Page 1128

Connection manual (Function)
18. TROUBLE DIAGNOSIS
B–64113EN–1/01
1110
1 Select thermal simulation or disturbance torque by page keys
[Page↑]/[Page↓].
2 Select axis by cursor keys [↑]/[↓].
3 Input numerical value by MDI key and press [INPUT] key.
Trouble forecast level is input into parameter No.8860 and 8861.
When Soft key [TRB LV] is pressed, the following soft keys appear.
[<][][][][] [] []
GUIDE W.PRM G–ADJ. TRB_LV (OPRT)
[<][][][][] [] []
–10% +10% –1% +1% INPUT
[–10%]: Subtract 10% from Trouble forecast level.
[ +10%]: Add 10% to Trouble forecast level.
[–1%]: Subtract 1% from Trouble forecast level.
[ +1%]: Add 1% to Trouble forecast level.
[INPUT]: Input Trouble forecast level by MDI key.
When thermal simulation or disturbance torque of servo axis exceeds
trouble forecast level, Trouble forecast signal TDFSVx (F298.0 – F298.3)
is output.
Parameters TRSx (No.8853/8854) need to be set to 1 to perform the
trouble forecast.
#7
8850
#6 #5 #4 #3 #2 #1 #0
MDG
[Data type] Bit
MDG Trouble diagnosis function is:
0 : Available.
1 : Not available.
#7
TRS88853
#6
TRS7
#5
TRS6
#4
TRS5
#3
TRS4
#2
TRS3
#1
TRS2
#0
TRS1
[Data type] Bit
TRS1 to TRS8 Trouble forecast is:
0 : Not available.
1 : Available.
Operation
Setting Trouble forecast
level
Change of Trouble
forecast level
Trouble forecast signal
Parameter
