12. DISPLAY/SET/EDIT
883
When KEY = 0
@ KEY1: Enables the input of tool compensation values and the
workpiece zero point offset values, and workpiece coordinate
systems shift amount.
@ KEY2: Enables the input of setting data and macro variables, and
tool life management data.
@ KEY3: Enables program loading and editing.
@ KEY4: Enables PMC data (counter data tables)
When KEY = 1
@ KEY1: Enables program loading and editing, as well as the input
of PMC parameters.
@ KEY2 to KEY4: Not used
[Operation] When a signal is set to 0, the associated operations are disabled.
When a signal is set to 1, the associated operations are enabled.
#7 #6 #5 #4 #3 #2 #1 #0
G046 KEY4 KEY3 KEY2 KEY1
#7 #6 #5 #4 #3 #2 #1 #0
KEY3290
KEY For memory protection keys:
0 : The KEY1, KEY2, KEY3, and KEY4 signals are used.
1 : Only the KEY1 signal is used.
NOTE
The functions of the signals depend on whether KEY = 0 or
KEY = 1.
Warning message Contents
WRITE PROTECT Data input is invalid because of memory pro-
tect signal.
Signal address
