12. DISPLAY/SET/EDIT

B–64113EN–1/01

852

[CNC maintenance screen]

PERIODICAL MAINTENANCE O0001 N12345

(NC)

ITEM NAME

01 BATTERY FOR CONTROLLER

02 BATTERY FOR PULSECODER

03 FAN MOTOR

04 LCD BACK LIGHT

EDIT *** ***** *** **** 19:27:05

[ ][ STATUS ][ MACHIN ][ NC ][ (OPRT) ]

[ SELECT ][ ][ ][ ][ ]

[ ][ ][ ][ CAN ][ EXEC ]

NOTE

On the CNC maintenance screen, it is impossible to register,

delete, input, and output item.

2) MDI–based setup

An item can be registered by first keying in data in the following

format, then pressing the [INPUT]. In addition, pressing the

[+INPUT] soft key can modify an existing item name.

NOTE

The asterisk (*) is used as a control code, so it cannot be

used in the item name. Likewise, square brackets “[” and

“]” and parentheses “(” and “)” must be excluded from the

item name.

To delete a registered item, place the cursor on it, and press the

[CLEAR] soft key, then the [EXEC] soft key.

When an item is deleted, the related service life, remaining

lifetime, and count type are also deleted.
