13. INPUT/OUTPUT OF DATA

B–64113EN–1/01

930

Symptom Cause and corrective action

When an attempt is made to output

macro variables to a power mate

CNC:

Series 0i/0i Mate:

Alarm 86 is issued.

Power mate CNC :

Alarm 1 is issued.

Bit 1 (ISO) of parameter No. 0000 is

set to 1 (EIA code).

The EIA code does not include #,

such that an ISO code must be set.

When an attempt is made to read

macro variables or diagnostic data

from a power mate CNC:

Series 0i/0i Mate:

LSK blinks continu-

ously.

Power mate CNC :

No response is re-

turned. (Caution)

A start number and the number of

data items to be transferred are not

set correctly in power mate CNC DI

signals G100 to G103.

Examples:

1 A ladder program error or I/O al-

location error prevented a start

number and the number of data

items from being transferred to

power mate CNC DI signals G100

to G103.

2 An invalid start number is speci-

fied, or the specified number of

data items to be transferred is in-

valid.

CAUTION

If these symptoms are detected, the Series 0i/0i Mate waits

for a condition to be satisfied in its internal processing.

While such a state exists, the screen is not updated. So, the

states of signals cannot be checked on a real–time basis on

a screen such as the PMC diagnostic screen.

[Classification] Input signal

[Function] This signal indicates that the Power Mate is performing data input/output.

[Operation] This signal is set to 1 when the power mate CNC is performing data

input/output.

This signal is a Power Mate state signal. The corresponding power mate

CNC side signal is RPBSY <F223#2>.

Signal

Power Mate read/write

in–progress signal

BGION <G092#2>
