15. PMC CONTROL FUNCTION
1025
#7
F182
#6 #5 #4 #3
EACNT4
#2
EACNT3
#1
EACNT2
#0
EACNT1
F190 TRQM4 TRQM3 TRQM2 TRQM1
1427 External deceleration speed of each axis
[Data type] Word axis
Increment system
Unit of data
Valid data range
Increment system
Unit of data
IS–B IS–C
Millimeter machine 1 mm/min 6 to 15000 6 to 12000
Inch machine 0.1 inch/min 6 to 6000 6 to 4800
Rotation axis 1 deg/min 6 to 15000 6 to 12000
#7
1803
#6 #5 #4
TQF
#3 #2 #1 #0
[Data type] Bit
TQF In torque control mode,
0 : Follow–up is not performed.
1 : Follow–up is performed.
1885 Permissible value of integrated travel distance under torque control
[Data type] Word axis
[Unit of data] Detection unit
[Valid data range] 0 to 32767
This parameter sets the maximum permissible value for the integrated
travel distance in torque control mode. If the integrated travel distance
exceeds the value set in this parameter, servo alarm No. 423 is issued.
NOTE
This parameter is valid when TQF (bit 4 of parameter No.
1803) is set to 0.
1886 Torque control cancel limit
[Data type] Word axis
[Unit of data] Detection unit
[Valid data range] 0 to 32767
This parameter sets the cancel limit value used to cancel torque control
mode.
When the position error falls below or is equal to the value set in this
parameter, torque control mode is canceled and position control becomes
effective.
Parameter
[Unit of data]
[Valid data range]
