13. INPUT/OUTPUT OF DATA
B–64113EN–1/01
938
Supplemental remark 1
If the DNC operation is performed with FOCAS1/HSSB, the setting
of parameter No. 20 does not matter. The DMMC signal <G042.7> is
used.
Supplemental remark 2
If bit 0 (IO4) of parameter No. 110 is set to control the I/O channels
separately, the I/O channels can be divided into four types: input and
output in the foreground and input and output in the background. If so,
parameter No. 20 becomes a parameter for selecting the input device
in the foreground.
8760 Program number for data registration (data input/output function using the I/O link)
[Data type] Word
[Valid data range] 0 to 9999
When the data input/output function using the I/O link is used, this
parameter sets the program numbers of the programs to be used for
registering data (parameters, macro variables, and diagnostic data) from
power mate CNCs.
For a power mate CNC in group n, the following program numbers are
used:
For parameters: Setting + n 10 + 0
For macro variables: Setting + n 10 + 1
For diagnostic data: Setting + n 10 + 2
Example: When 8000 is set
8000: Parameters of group 0 (I/O channel = 20)
8001: Macro variables of group 0 (I/O channel = 20)
8002: Diagnostic data of group 0 (I/O channel = 20)
8010: Parameters of group 1 (I/O channel = 21)
8011: Macro variables of group 1 (I/O channel = 21)
8012: Diagnostic data of group 1 (I/O channel = 21)
8020: Parameters of group 2 (I/O channel = 22)
8021: Macro variables of group 2 (I/O channel = 22)
8022: Diagnostic data of group 2 (I/O channel = 22)
8150: Parameters of group 15 (I/O channel = 35)
8151: Macro variables of group 15 (I/O channel = 35)
8152: Diagnostic data of group 15 (I/O channel = 35)
NOTE
When 0 is set, the input/output of parameters, macro
variables, and diagnostic data cannot be performed, but
program input/output processing is performed.
