0i/0i Mate - Model C Connection manual (Function) Page 1137

Connection manual (Function)

Page of 1224

/ 1224

B–64113EN–1/01

18. TROUBLE DIAGNOSIS

1119

As a result of CNC alarm diagnosis, the alarm may be caused by machine

trouble.

Considering such a case, it is possible to jump to MTB’s guidance table

from CNC guidance table by the special message IDs starting with ”M”.

If the flowing special message IDs stating with ”M” are created in MTB’s

guidance table, a jump to MTB’s guidance table from CNC guidance table

becomes available.

No. Message ID Alarm name Presumed cause

1 M205 Rigid mode DI OFF The rigid mode DI signal (G061.0) is not set to 1 when the

rigid tapping is executed.

2 M409 Abnormal load detected A mechanical collision or twist occurred, resulting in a load

torque higher than a normal operation value.

3 M410 Excessive stop error A mechanical collision or twist occurred, disabling an axis

from reaching a target position.

4 M411 Excessive move error A mechanical collision or twist occurred, disabling an axis

from moving.

5 M420 Excessive torque

difference

Two axes to be moved synchronously lost mechanical syn-

chronism with each other, resulting in a large torque differ-

ence.

6 M421 Excessive semi–closed

loop error

With a closed–loop machine, a shift occurred between the

motion of the motor and the motion of the separate detector

for a cause such as a mechanical twist.

7 M436 OVC alarm A mechanical collision or twist occurred, resulting in a large

load and the flow of an excessive current.

CAUTION

All message IDs starting with ”M” are reserved for a jump to

MTB’s guidance table from a CNC guidance table.

In the future, a message ID to which a jump is made from

a CNC guidance table may be added. So, do no use a

message ID starting with ”M” which may or may not be

included in the table above for the other purpose.

Jump from CNC

guidance table to MTB’s

guidance table

Reserved message IDs
