0i/0i Mate - Model C Connection manual (Function) Page 1191

Connection manual (Function)

Page of 1224

/ 1224

B–64113EN–1/01

A. INTERFACE BETWEEN CNC AND PMC

1173

Group

Referen

ce item

series

Address Signal nameSymbol

EF External operation signal F008#0 – f 11.7

EFD External operation signal for high-speed interface F007#1 – f

8.4

EFIN External operation function completion signal G005#1 – f

8.4

EFINA

Auxiliary function completionsignal (PMC axis

G142#0 f f

15.1

EFINB

Auxiliary function completionsignal (PMC axis

control)

G154#0 f f

15.1

EFINC

Auxiliary function completionsignal (PMC axis

control)

G166#0 f f

15.1

EFIND G178#0 f f

EGENA

Axis moving signal (PMC axis control)

F130#4 f f

15.1

EGENB

Axis moving signal (PMC axis control)

F133#4 f f

15.1

EGENC

Axis moving signal (PMC axis control)

F136#4 f f

15.1

EGEND F139#4 f f

15.1

EIALA

Alarm signal (PMC axis control)

F130#2 f f

15.1

EIALB

Alarm signal (PMC axis control)

F133#2 f f

15.1

EIALC

Alarm signal (PMC axis control)

F136#2 f f

15.1

EIALD F139#2 f f

15.1

EID0A to EID31A

Axis control data signal (PMC axis control)

G146 to G149 f f

15.1

EID0B to EID31B

Axis control data signal (PMC axis control)

G158 to G161 f f

15.1

EID0C to EID31C

Axis control data signal (PMC axis control)

G170 to G173 f f

15.1

EID0D to EID31D G182 to G185 f f

EIF0A to EIF15A

Axis control feedrate signal (PMC axis control)

G144,G145 f f

EIF0B to EIF15B

Axis control feedrate signal (PMC axis control)

G156,G157 f f

EIF0C to EIF15C

Axis control feedrate signal (PMC axis control)

G168,G169 f f

EIF0D to EIF15D G180,G181 f f

EINPA

In position signal (PMC axis control)

F130#0 f f

EINPB

In-position signal (PMC axis control)

F133#0 f f

EINPC

position signal (PMC axis control)

F136#0 f f

EINPD F139#0 f f

EKC0 to EKC7 Key code signal G098 f f

15.5

EKENB Key code read completion signal F053#7 f f

15.5

EKSET key code read signal G066#7 f f

ELCKZA

Accumulated zero check signal

G142#1 f f

15.1

ELCKZB

Accumulated zero check signal

G154#1 f f

15.1

ELCKZC

Accumulated zero check signal

G166#1 f f

15.1

ELCKZD G178#1 f f

15.1

EM11A to EM48A

Auxiliary function code signal (PMC axis control)

F132,F142 f f

15.1

EM11B to EM48B

Auxiliary function code signal (PMC axis control)

F135,F145 f f

EM11C to EM48C

Auxiliary function code signal (PMC axis control)

F138,F148 f f

EM11D to EM48D F141,F151 f f
