10. TOOL FUNCTIONS
701
Bit 0 (WOF) of parameter No. 3290 = 1 (Disables tool wear compensation
value modification.)
Parameter No. 3294 = 100
Parameter No. 3295 = 11
If bit 0 (WOF) of parameter No. 3290 is set to 0, the modification of the
tool geometry compensation values alone is disabled. The tool wear
compensation values may be modified.
#7 #6 #5 #4 #3 #2 #1 #0
WNP5002 LGN
[Data type] Bit
LGN Geometry offset number of tool offset
0 : Is the same as wear offset number
1 : Specifies the geometry offset number by the tool selection number
WNP Imaginary tool tip direction used for tool nose radius compensation is the
direction specified by:
0 : Geometry offset number
1 : Wear offset number
#7 #6 #5 #4 #3 #2 #1 #0
5004 ORC
[Data type] Bit
ORC Tool offset value
0 : Set by the diameter specification (Can be set in only the axis under
diameter programming)
1 : Set by the radius specification
#7 #6 #5 #4 #3 #2 #1 #0
5006 OIM
[Data type] Bit
OIM When the unit is switched between the inch and metric systems, automatic
tool compensation value conversion is:
0 : Not performed
1 : Performed
