12. DISPLAY/SET/EDIT
811
3120 Time from the output of an alarm to the termination of sampling
[Data type] Word
[Unit of data] ms
[Valid data range] 1 to 32760
When the waveform diagnosis function is used, this parameter sets the
time form the output of a servo alarm until data collection. Storage
operation is stopped because of the alarm. (This means that the
termination of data collection can be delayed by a specified time.)
3121 Store–type waveform diagnosis data select
[Data type] Byte
[Valid data range] 0 to 1
The six types of sampling data in store–type waveform diagnosis are:
0 : Thermal simulation data.
1 : Spindle load meter.
NOTE
1 Once the memory area becomes full, the oldest data is
deleted to allow new data.
2 Waveform diagnosis data is held in memory even after the
power is turned off.
3 Be careful to set the date and time correctly.
4 Waveform diagnosis is enabled when bit 0 (SGD) of
parameter No. 3112 is set to 1.
Usual graphic display function can not be used when
waveform diagnosis is enable.
Series 0i–C/0i Mate–C
MAINTENANCE MANUAL
(B–64115EN)
Waveform diagnostic display
Note
Reference item
Previous page
Next page
