0i/0i Mate - Model C Connection manual (Function) Page 420

Connection manual (Function)

Page of 1224

/ 1224

B–64113EN–1/01

7. FEEDRATE CONTROL/ACCELERATION

AND DECELERATION CONTROL

402

1781

Allowable speed difference for the speed difference–based corner deceleration

function (linear acceleration/deceleration after interpolation)

[Data type] Word axis

Increment system

Unit of data

Valid data range

Increment s

stem

Unit of data

IS-A, IS-B IS-C

Millimeter machine 1 mm/min 6 to 15000 6 to 12000

Inch machine 0.1 inch/min 6 to 6000 6 to 4800

Rotation axis 1 deg/min 6 to 15000 6 to 12000

Set speed difference for the speed difference–based automatic corner

deceleration function when linear acceleration/deceleration after

interpolation used.

CAUTION

1 Even during dry run or external deceleration, the feedrate

difference is checked according to the F command in the

program.

2 If the G09 (exact stop) command is executed, an exact stop

is performed, and Automatic Corner Deceleration is not

executed.

3 This function is invalid for the feed per rotation command,

F1–digit feed command (M series), and rigid tapping

command, as well as in single block mode.

4 If the override is changed during operation, the feedrate

difference cannot be checked correctly.

This function is designed for high–speed precise machining. With this

function, the delay due to acceleration/deceleration and the delay in the

servo system which increase with the feedrate can be suppressed.

The tool can then follow specified path accurately and errors in the

machining profile can be reduced.

This function becomes effective when advanced preview control mode is

activated by G08P1 command.

In advanced preview control mode, the following functions are available:

(1)Linear acceleration/deceleration before interpolation for cutting feed

(2)Automatic corner deceleration function

[Unit of data]

[Valid data range]

Caution

7.1.12

Advanced Preview

Control

General

D Available functions
