B–64113EN–1/01

14. MEASUREMENT

953

NOTE

1 Measurement speed, γ, and ε are set as parameters.ε must

be positive numbers and satisfy the condition of γ>ε.

2 The compensation value is updated by the following

formula:

New compensation value =(Current compensation

value)+[(Current position of the

tool along the specified axis

when the measuring position

reached signal is “1”) –

(specified measuring position)]

The following compensation values are updated:

(1)In a M series, the compensation value corresponding to

the tool compensation number selected by an H code.

The tool wear compensation value for the H code is

changed.

(2)In a T series, the compensation value corresponding to

the tool compensation number selected by a T code and

to the specified axis (X, Z) in G36, G37.

3 The maximum measuring error is calculated as shown

below.

ERRmax: Maximum measuring error (mm)

Fm : Measuring feedrate (mm/min)

If Fm = 100 mm/min, for example, ERRmax = 0.007 mm

4 After the measuring position reached signal has been

detected, the tool moves for a maximum of 20 msec, then

stops. Values for calculating the compensation amount,

that is the coordinate of the tool where the tool reached the

measuring position are not those obtained after stop, but

those obtained at the position where the measuring position

reached signal was detected.

The overtravel amount for 20 msec is calculated as follows.

Qmax: Maximum overtravel amount (mm)

Fm : Measuring feedrate (mm/min)

Ts : Servo time constant [msec] (1/loop gain)

ERRmax = Fm ×

60 1000

Qmax = Fm × ×

60 1000

(20 + Ts)
