11. PROGRAM COMMAND
B–64113EN–1/01
728
Table 11.2 G code list for T series (3/3)
G code
Group
Function
A B C
Group
Function
G71 G71 G72
01
Traverse grinding cycle (for grinding machine)
G72 G72 G73
01
Traverse direct constant–dimension grinding cycle
(for grinding machine)
G73 G73 G74
01
Oscilation grinding cycle (for grinding machine)
G74 G74 G75
Oscilation direct constant–dimension grinding cycle
(for grinding machine)
G80 G80 G80
10
Canned cycle for drilling cancel
G83 G83 G83
10
Cycle for face drilling
G84 G84 G84
10
Cycle for face tapping
G86 G86 G86
10
Cycle for face boring
G87 G87 G87 Cycle for side drilling
G88 G88 G88 Cycle for side tapping
G89 G89 G89 Cycle for side boring
G90 G77 G20
01
Outer diameter/internal diameter cutting cycle
G92 G78 G21
01
Thread cutting cycle
G94 G79 G24 Endface turning cycle
G96 G96 G96
02
Constant surface speed control
G97 G97 G97
02
Constant surface speed control cancel
G98 G94 G94
05
Per minute feed
G99 G95 G95
05
Per rotation feed
* G90 G90
03
Absolute programming
* G91 G91
03
Incremental programming
* G98 G98
11
Return to initial level
* G99 G99
11
Return to R point level
