5. AUTOMATIC OPERATION

B–64113EN–1/01

276

[Classification] Output signal

[Function] Notifies the PMC that feed hold state is entered.

[Output condition] This signal is set to 1 or 0, according to the state of the CNC, as listed in

Table 5.1.

Signals OP, STL, and SPL are the signals to inform PMC of the operation

condition of CNC.

Table 5.1 Status of operation

Signal name

State of

the operation

Cycle start

lamp

STL

Feed hold

lamp

SPL

Automatic

operation

lamp

Cycle start state 1 0 1

Feed hold state 0 1 1

Automatic operation stop

state

0 0 1

Reset state 0 0 0

· Cycle start state

The CNC is executing memory operation or manual data input

operation commands.

@ Feed hold state

The CNC is not executing memory operation nor manual data input op-

eration commands while the commands to be executed remain.

@ Automatic operation stop state

Memory operation or manual data input operation has been completed

and stopped.

@ Reset state

The automatic operation has been forcibly terminated.

NOTE

If the sequence number search is performed through MDI

panel during Memory mode (MEM), the signal OP turns to

“1”.

#7 #6 #5 #4 #3 #2 #1 #0

*SP

G007

G008

OPF000 STL SPL

#7 #6 #5 #4 #3 #2 #1 #0

Feed hold lamp signal

SPL <F000#4>

D Signal address
