0i/0i Mate - Model C Connection manual (Function) Page 166

Connection manual (Function)
B–64113EN–1/01
2. PREPARATIONS FOR OPERATION
148
WARNING
1 Whenever the two check limits are set to the same value, the
following results are seen.
(1)In the case of stored stroke check 1, all areas are
prohibited.
(2)In the case of stored stroke check 2 or 3, no areas are
prohibited.
2 Whenever the value of the negative limit is greather than the value
of the positive limit, the following results are seen.
(1) In the case of stored stroke check 1, no areas are
prohibited.
(2) In the case of stored stroke check 2 or 3, the prohibited
area will consists of a quadrangle formed with the two
points acting vertexes.
NOTE
Parameter BFA (bit 7 of No. 1300) selects whether an alarm
is displayed immediately before the tool enters the
forbidden area or immediately after the tool has entered the
forbidden area. (check 1, 3 only)
Series 0i–C
OPERATOR’S MANUAL
(M series) (B–64124EN)
III.6.3 Stored stroke check
Series 0i–C
OPERATOR’S MANUAL
(T series) (B–64114EN)
III.6.3 Stored stroke check
Series 0i Mate–C
OPERATOR’S MANUAL
(M series) (B–64144EN)
III.6.3 Stored stroke check
Series 0i Mate–C
OPERATOR’S MANUAL
(T series) (B–64134EN)
III.6.3 Stored stroke check
Warning
Note
Reference item
Previous page
Next page
