11. PROGRAM COMMAND
743
SBV Custom macro statement
0 : Not stop the single block
1 : Stops the single block
To control single blocks in custom macro statements using system
variable #3003, use this parameter to enable or disable single blocks in
custom macro statements.
This bit is valid when bit 5 (SBM) of parameter No. 6000 is set to 0.
#7 #6 #5 #4 #3 #2 #1 #0
CLV6001 CCV TCS CRO PV5 PRT
[Data type] Bit
PRT Reading zero when data is output using a DPRNT command
0 : Outputs a space
1 : Outputs no data
PV5 Custom macro common variables
0 : Outputs custom macro common variables #500 through #599.
1 : Outputs custom macro common variables #100 through #199 and
#500 through #599.
CRO ISO code output using a BPRNT command or a DPRNT command
0 : Outputs only LF after data is output
1 : Outputs LF and CR after data is output
TCS Custom macro (subprogram)
0 : Not called using a T code
1 : Called using a T code
CCV Custom macro’s common variables Nos. 100 through 149
0 : Cleared to “vacant” by reset
1 : Not cleared by reset
CLV Custom macro’s local variables #1 through #33
0 : Cleared to “vacant” by reset
1 : Not cleared by reset
#7 #6 #5 #4 #3 #2 #1 #0
*76010 *6 *5 *4 *3 *2 *1 *0
=76011 =6 =5 =4 =3 =2 =1 =0
#76012 #6 #5 #4 #3 #2 #1 #0
[76013 [6 [5 [4 [3 [2 [1 [0
]76014 ]6 ]5 ]4 ]3 ]2 ]1 ]0
[Data type] Bit
These parameters are used to input/output macro statements with EIA
code.
The numeral of a suffix indicates the bit position in a code.
D Other settings
D Setting when macro
statement is input/output
with EIA code
