0i/0i Mate - Model C Connection manual (Function) Page 610

Connection manual (Function)
B–64113EN–1/01
9. SPINDLE SPEED FUNCTION
592
#7
3700
#6 #5 #4 #3 #2 #1
NRF
#0
[Data type] Bit
NRF Once the Cs contour control mode has been entered, the first positioning
command G00:
0 : Makes a reference position return.
1 : Performs normal positioning.
To use the Cs axis coordinate setup function, it is recommended to specify
NRF = 1.
#7
3712
#6 #5 #4 #3 #2
CSF
#1 #0
[Data type] Bit
CSF If the origin has been set up, automatic setting of the machine and work
coordinates according to the machine position of the spindle during Cs
contour control mode is:
0 : Disabled.
1 : Enabled.
#7
4353
#6 #5
CSPTRE
#4 #3 #2 #1 #0
[Data type] Bit axis
CSPTRE Cs axis position data transfer is:
0 : Disabled.
1 : Enabled.
To use this function, reset the RFOHK3 parameter (bit 7 of parameter No.
4016) to 0.
[Classification] Input signal
[Function] The Cs axis coordinate setup function is executed.
[Operation] If this signal is ”1”, the control unit behaves as follows:
If the signal is ”1” during Cs contour control mode, the work and machine
coordinates are set up according to the machine position of the Cs axis.
If this signal is ”0”, the control unit behaves as follows:
The Cs axis coordinate setup alarm signal CSFO1 <F274#4> is reset to
’0’.
Signal
Cs axis coordinate setup
request signal
CSFI1 <G274#4>
