1425 FL rate of the reference position return for each axis

[Data type] Word axis

Increment system

Unit of data

Valid data range

Increment s

stem

Unit of data

IS-A, IS-B IS-C

Millimeter machine 1 mm/min 6 – 15000 6 – 12000

Inch machine 0.1 inch/min 6 – 6000 6 – 4800

Rotaion axis 1 deg/min 6 – 15000 6 – 12000

Set feedrate (FL rate) after deceleration when the reference position return

is performed for each axis.

1800

#6 #5 #4 #3 #2

OZR

#1 #0

[Data type] Bit

OZR When manual reference position return is attempted in feed hold during

automatic operation under any of the conditions listed below:

0: Manual reference position return is not performed, with P/S alarm No.

091.

1: Manual reference position return is performed without an alarm

occurring.

< Conditions >

D When there is a remaining distance to travel.

D When a auxiliary function (miscellaneous function, spindle–speed

function, tool function, B function) is being executed.

D When a dwell or cycle such as a canned cycle is being executed.

1821 Reference counter size for each axis

[Data type] Two–word axis

[Valid data range] 0 to 99999999

Set the size of the reference counter.

To set the size of the reference counter, specify the grid interval for the

reference position return in the grid method.

Size of the reference counter =

detection unit

grid interval

Grid interval = the amount of travel per rotation of the pulse coder

NOTE

When this parameter has been set, the power must be

turned off before operation is continued.

[Valid data range]

[Unit of data]
